◆ 使用UHF550-950MHz频段,应用PLL频率合成锁相环技术,频率可调,发射功率可调,避免干扰频率 ◆ 集成中央处理器CPU的总线控制,配合数字液晶界面显示,操作自如,性能出众。 ◆ 采用多级窄带高频及中频选频滤波,充分消除干扰信号。 ◆ 采用音频压缩一扩展技术,噪音大大减少,动态范围加大。 ◆ 设有回输啸叫抑制减弱功能,能有效减少回输啸叫。 ◆ 接收机采用多级高频放大,具有极高的灵敏度。 ◆ 多重噪音监测电路,特设ID身份码验证系统,使之具有无与伦比的抗干扰特性,支持10台叠机使用(即10台接收机和80个发射器)。 ◆ 选用极佳晶片及优质零部件,使本机音质极为出色。 ◆空阔最大使用范围100米以上,理想空阔使用范围60米。 ◆ 可任意选配手咪、头戴、领夹、鹅颈。 接收机 ◆ 载波频率:550-950MHz(可调) ◆ 电源适配器使用电压:AC110V-230V 50Hz/60Hz(请按机壳和电源适配器标注使用) ◆ 直流输入电压:DC12—DC15V 1500mA ◆ 消耗功率:13W ◆ S/N信噪比:≥95dB ◆ T.H.D失真:<0.5% ◆ 频率响应:60Hz -16KHz 发射机 ◆ 载波频率:550-950MHz ◆ 发射功率:10dBm ◆ 输入音频调制信号选择:MIC IN电容咪输入(内供电)LINE IN音频线路输入 ◆ 调制方式:FM ◆ 最大调制度:±45KHz ◆ 高次谐波:低于主波基准60dB以上 ◆ 使用电池电压:3V(2节AA1.5V碱性电池或高容量AA1.2V-1800mAh充电电池) ◆ 连续使用时间:8小时
1.面板采用高档铝合材料精心加工而成,机器内部局部采用SMT技术。 2.高效率的环形变压器,保证充足电源供应。 3.功放电路选用半导体进口元器件,每只元件有足够的余量。 4.散热风扇采用无级调速电路,保证了功放工作在较低的温度下。 5.配有信号输入口与并联信号输出口。功放输出端配有Speakon和接线柱,适用与 各种系统的安装要求。 6.完善的保护,包括限幅,直流,开/关机冲击电路,输出短路保护,过热保护。 型号 MA-4 输出功率/Power8Ω 450W×2 输出功率/Power4Ω 750W×2 频率响应 20HZ—20KHZ:±0.5Db 输入灵敏度 1V 信噪比 >103DB 总谐波失真 ≤0.05% 输入阻抗 平衡20KΩ/非平衡10KΩ 消耗功率 1300W 外型尺寸 485*490*88
